• Lighter & Stronger pressed steel body with Monocoque construction. Outstanding structural strength and unmatched durability. Robotic Automated welding for best-in-class build quality
  • Powered by the Mercedes derived FM 2.6 CR ED BS-VI engine derived from Mercedes designs and adapted to Indian conditions. Best in class fuel mileage
  • India’s first product to have the option of sliding doors on driver and co-driver side in addition to 0 270 opening rear door. Ensures easy loading and unloading of cargo. Low loading height for T1 750 mm & T2 775 mm
  • Vehicle tracking and surveillance system (optional) India’s 1st product with live tracking and live footage streaming for enhanced safety
  • Red & White colour options
  • Sliding door (option) for kerb side delivery
  • Product Description

VARIANT

Diesel

ENGINE

ModelFM2.6CR ED
EmissionBS-VI
Type4 Cyl. Common Rail, DI TCIC
Displacement2596 cc
Max Output85kW (115 hp) @ 2950 rpm
Max Torque350 Nm @ 1400 - 2200 rpm

TRANSMISSION

TypeSynchromesh
ModelG32-5
No. of Gears5Front +1Reverse

SUSPENSION

FrontSpring Semi elliptical, hydraulic shock absorbers and anti roll bar
RearSpring Semi elliptical, hydraulic shock absorbers and anti roll bar(optional)

STEERING

TypePower Steering

BRAKES

Service BrakesHydraulic, Dual circuit, vacuum assisted, auto slack adjuster, ABS with EBD(optional)
FrontDisc
RearDrum / (Disc only on 4020WB)
ParkingMechanical acting on rear wheels

WARRANTY

Warranty3 years / 3 lakh km* with 6 free services * T&C apply

WHEELS & TYRES

Size215/75215/75 R15215/75 R15235 / 65 R16
Tyre TypeRadial tubless with Tube / (4 + 1 Tyre)

DIMENSIONS

Wheel Base (mm)3050335037004020
Overall Length (mm)5135561562656966
Overall Width (mm)1900
Overall Height (mm)2550
Cargo Box (L x W x H)2820 X 1680 X 18303300 X 1680 X 18303950 X 1680 X 18304653 X 1680 X 1830
Ground Clearance (mm)200

WEIGHTS

( kg )
Max. Permissible GAW3870390541254375
Rated Payload1600160017001800

CAPACITY

Fuel Tank70 litres

SEATING CAPACITY

Seating CapacityD + 1
